Complicated Corner dabtsi yog khoov Cnc Hlau dabtsi yog khoov tshuab

CNC hlau dabtsi yog khoov tshuab yog los tsim hom 2D thiab 3D hlau cov ntaub ntawv kws txawj nrog siab precision thiab ceev ceev. Txais Japanese branded servo lub cev muaj zog thiab tshuaj ntsuam zaub nrog cov tswj zoo. Kev ua haujlwm yooj yim thiab ceev tig-key.

Xa kev nug

Tsham tam sim no

Khoom Taw qhia

CNC hlau dabtsi yog khoov tshuab yog los tsim hom 2D thiab 3D hlau cov ntaub ntawv kws txawj nrog siab precision thiab ceev ceev.

Adopts Japanese branded servo lub cev muaj zog thiab tshuaj ntsuam zaub nrog cov tswj zoo. Kev ua haujlwm yooj yim thiab ceev tig-key.

1. Qhov zoo & Nta:

3-4 khub pub rau menyuam, pub lub cev muaj zog ruaj khov rau hauv qab lub hauv paus, kom txo tau lub thawv ntim khoom noj, cov xaim rotating yog ceev dua thiab lub teeb, tig lub kaum sab xis ntau dua thiab ruaj khov.

2. Daim ntawv thov teb:

1）Auto Industry cheeb tsam

2）Kev lag luam hlau hlau

3）Zaub rooj thiab cargo txee

4）Rooj tog thiab chav ua noj

5）Kev lag luam kho vajtse

6）Txaj txaj, Sofa caij nplooj ntoos hlav cheeb tsam

7）cheeb tsam vaj tsev

8）Kho vajtseArtcraft

3. Technical Paramter

Qauv	GT-WB-100-9A	GT-WB-80-8A	GT-WB-70-10A	GT-WB-70-8A	GT-WB-70-7A
Hlau loj	4. 0-10 0mm	4. 0-9 0mm	2. 0-7 0mm	2. 0-7 0mm	2. 0-7 0mm
Axis	9	8	10	8	7
hlau pub nqi(mm)	Max. 10000.00 Min.0.01	Max. 10000.00 Min.0.01	Max. 10000.00 Min.0.01	Max. 10000.00 Min.0.01	Max. 10000.00 Min.0.01
Pub tus naj npawb ntev	3 sib	3 sib	3 sib	3 sib	3 sib
Hlau tig lub kaum sab xis	Unlimited	Unlimited	Unlimited	Unlimited	Unlimited
Platform Lifting Qhov siab	ua plus25-120 hli	ua plus25-120 hli	ua plus25-120 hli	ua plus25-120 hli	ua plus25-120 hli
twisting taub hau nqa qhov siab	plus 20-180 hli	plus 20-180 hli	plus 20-180 hli	plus 20-180 hli	plus 20-180 hli
sab laug mus rau sab xis txav ntau	Sab laug:100 hli Txoj cai:50 hli	Sab laug:100 hli Txoj cai:50 hli	Sab laug:100 hli Txoj cai:50 hli	Sab laug:100 hli Txoj cai:50 hli	Sab laug:100 hli Txoj cai:50 hli
Pub rau pem hauv ntej thiab rov qab txav ntau yam	Pem hauv ntej: 300mm Rov qab:100 hli	/	Pem hauv ntej: 300mm Rov qab:100 hli	/	/
Tag nrho cov zis zog ntawm servo motors	27.8 kWm	25.8 KW TSI	24.2 KW UA	17.5	16.2 KW TSI
Tsis siv neeg decoiler	1000 KG	800 KG	500 KG	500 KG	500 KG
tshuab loj(cm)	420x152x160	420x152x160	380x1520x1600	260x122x160	250x122x160
tshuab hnyav	4500.0(kg)	4200.0(kg)	3800.0(kg)	3200.0(kg)	2800(kg)
